The WELLS air handler unit for the Multi Zone Series offers a powerful, centralized solution for ducted indoor air distribution as part of a multi-zone.
| Wells Multizone Air Handler Unit | |||
| Model | WMA-18HFMAH | WMA-24HFMAH | |
| Performance | |||
| Power Supply(V, Ph, Hz) | 208/230, 1, 60 | 208/230, 1, 60 | |
| Air Flow Volume(CFM) | H/M/L | 576/529/488 | 758/694/629 |
| Noise Level(dB(A)) | H/M/L | 38.5/35/34 | 42/40/38.0 |
| Indoor Unit | |||
| Net Dimension(inch) | W x D x H | 21.02×17.52×45.00 | 21.02×17.52×45.00 |
| Package Dimension(inch) | W x D x H | 26.57×20.87×48.62 | 26.57×20.87×48.62 |
| Net/Gross Weight(lbs) | 106.70/127.21 | 106.70/127.21 | |
